Display
Size
10.4 inches
Touch / Glass
Projected Capacitive Multi Touch Screen
Resolution
1024×768
Panel Brightness
350.0 nits
Contrast Ratio
1000:1
View Angles
88,88,88,88
Active Area
210.4×157.8 mm
System Specification
Processor
Intel® Celeron® N6211 ( up to 3.0GHz) Intel® Celeron® N6210 (up to 2.6GHz) (Optional)
Memory
1 x SO-DIMM, DDR4 3200 MHz, 4GB 8GB (Optional) 16GB (Optional)
Storage
1 x M.2 2242 B-key SSD 128GB 256GB (Optional) 512GB 1 x SATA III for 2.5″ SSD/HDD up to 1TB (Optional)
Ethernet controller
2 x Intel® Ethernet Controller
Security
TPM 2.0
Operating System
Windows 11 IoT Enterprise (64 bit) (Optional) Windows 11 Pro 64 bit (Optional) Windows 10 IoT Enterprise (64 bit) (Optional) Linux Ubuntu 22.04 (Optional)
WLAN
Support (Optional)
BT
Support (Optional)
Mechanical
Dimension
284 x 252 x 55.39 mm
Cut out
262 x 220mm
Weight
2.3 kg
Mounting
Panel mount VESA Mount
Enclosure
Metal Housing
Cooling System
Fanless design
Environment
Operating Humidity
10% to 90% RH, Non-Condensing
Operating Temperature
0°C to 50°C
Storage Temperature
-10°C to 60°C
IP rating
Front IP65
Certification
Certification
CE, FCC
IO Ports
USB Port
2 x USB3.2 Gen2x1 (Type-A)
Serial Port
1 x RS232/422/485 (Default RS232) 1 x RS232
LAN
2 x Giga LAN RJ45 Connector
Video
1 x HDMI 2.0 (Optional)
Audio
2 x Speaker
Expansion Port
1 x M.2 2242 B-Key Slot (for SATA III SSD) 1 x M.2 2230 E-Key Slot (for Wi-Fi module)
Indicator
1 x LED Indicator for power 1 x LED Indicator for storage
Brightness Knob
1 x Brightness Adjustment Knob
Power Input
1 x 12V DC, 2.5? DC jack
Control
Button
1 x Power Button 1 x Reset Button
Accessory
Accessory
100~240V AC to DC Adapter Power Cord VESA screws Mounting clips
Power
Power Rating
12V DC
Adapter
12V 50W
