System Specification
Processor
Intel Pentium N4200 1.1GHz (up to 2.5GHz)
Memory
1 x SO-DIMM, DDR3L 1600 MHz, 4GB 8GB (Optional)
Storage
1 x M.2 B-Key 2242 SSD 128GB M.2 B-Key 2242 SSD up to 512GB (Optional)
Ethernet controller
2 x Intel® Ethernet Controller
Security
TPM 2.0
Operating System
Windows 10 IoT Enterprise (64 bit) (Optional) Linux Ubuntu 20.04 (Optional)
WLAN
Support (Optional)
BT
Support (Optional)
RFID
HF RFID Reader 13.56 MHz (Optional)
Light Bar
Built-in RGB LED Status Light Bar, on both sides
Display
Size
7.0 inches
Touch / Glass
Projected Capacitive Multi Touch Screen
Resolution
1024×600
Panel Brightness
320.0 nits
Contrast Ratio
1000:1
View Angles
75,75,75,70
Active Area
153.6×90 mm
Mechanical
Dimension
189.4 x 145.4 x 36.1 mm
Cut out
175.5×131.5mm
Mounting
Panel mount VESA Mount
Enclosure
Metal Housing
Cooling System
Fanless design
Environment
Operating Humidity
10% to 90% RH, Non-Condensing
Operating Temperature
0°C to 50°C
Storage Temperature
-10°C to 60°C
IP rating
Front IP65
Certification
Certification
CE, FCC
IO Ports
USB Port
2 x USB3.2 Gen1x1 (Type-A)
Serial Port
1 x RS232/422/485 (Default RS232)
LAN
2 x Giga LAN RJ45 Connector, One with PoE(PD, 802.3bt, 40W)(Optional)
Video
1 x Micro HDMI (Optional)
Audio
1 x Speaker
Expansion Port
2 x M.2 slot(1 for WiFi, 1 for SSD)
Power Input
1 x 12V DC, 3-Pin Terminal Block
Accessory
Accessory
100~240V AC to DC Adapter Power Cord Terminal Block to 2.5Ø Female Adapter Cable Open Wire Cable with terminal block connector VESA screws
Optional Accessory
VESA Wall Mount (Optional) VESA Desk Stand (Optional) Glass Wall Mount Kit (Optional) Front Side Wall Mount (Optional) VESA bracket mounting kit (Optional)
Power
Power Rating
12V DC 10~60V (Optional)
Adapter
12V 50W
POE
