Size
7.0 inches
Touch / Glass
Projected Capacitive Multi Touch Screen
Resolution
1024×600
Panel Brightness
320.0 nits
Contrast Ratio
1000:1
View Angles
75,75,75,70
Active Area
153.6×90 mm
Processor
Intel® Celeron® N6211 ( up to 3.0GHz) Intel® Celeron® N6210 (up to 2.6GHz) (Optional)
Memory
1 x SO-DIMM, DDR4 3200 MHz, 4GB 8GB (Optional) 16GB (Optional)
Storage
1 x M.2 2242 B-key SSD 128GB 256GB (Optional) 512GB 1 x SATA III for 2.5″ SSD/HDD up to 1TB (Optional)
Ethernet controller
2 x Intel® Ethernet Controller
Security
TPM 2.0
Operating System
Windows 11 IoT Enterprise (64 bit) (Optional) Windows 11 Pro 64 bit (Optional) Windows 10 IoT Enterprise (64 bit) (Optional) Linux Ubuntu 22.04 (Optional)
WLAN
Support (Optional)
BT
Support (Optional)
Dimension
184.94 x 127.7 x 48.2 mm
Cut out
175 x 117mm
Weight
1.5 kg
Mounting
Panel mount VESA Mount
Enclosure
Plastic Front Bezel with Metal Back Cover
Cooling System
Fanless design
Operating Humidity
10% to 90% RH, Non-Condensing
Operating Temperature
0°C to 50°C
Storage Temperature
-10°C to 60°C
IP rating
Front IP65
Certification
CE, FCC
USB Port
2 x USB3.2 Gen2x1 (Type-A)
Serial Port
1 x RS232/422/485 (Default RS232) 1 x RS232
LAN
2 x Giga LAN RJ45 Connector
Video
1 x HDMI 2.0 (Optional)
Audio
2 x Speaker
Expansion Port
1 x M.2 2242 B-Key Slot (for SATA III SSD) 1 x M.2 2230 E-Key Slot (for Wi-Fi module)
Indicator
1 x LED Indicator for power 1 x LED Indicator for storage
Power Input
1 x 12V DC, 2.5? DC jack
Accessory
100~240V AC to DC Adapter Power Cord VESA screws Mounting clips
Power Rating
12V DC
Adapter
12V 50W
