| Weight | 3000 g |
|---|---|
| Dimensions | 355 × 225 × 55 mm |
| Form-factor | Panel |
| CPU | ARM: Raspberry Pi® CM4 |
| FLASH | 16GB |
| External storage | 1 TF card slot designed for storage expansion |
| Display size | 13.3? |
| Resolution | 1920*1080 |
| Brightness (NIT) | 400 NIT |
| Touch Screen | Capacitive |
| WiFi/BT | Depends on the Compute Module 4 selected. |
| ZIGBEE | Supported, NOT mounted by default |
| 4G | Supported, NOT mounted by default |
| Ethernet | 1x Giga LAN |
| Audio | 3.5mm Audio Out Connector, Internal 2W Speaker |
| Buzzer | Onboard Buzzer, driven by GPIO |
| USB | 2 x USB 3.0 Host, 1 x USB OTG |
| RTC | High Accuracy RTC with Lithium Button Coin battery, can work 1 week after power off (lithium battery not included) |
| GPIO | 8 Channels, 4 Input, 4 Output |
| RS485 | 2x RS485 |
| RS232 | 2x RS232 |
| CAN | 1 x CAN-BUS |
| OS | Raspberry Pi OS |
| Power Input | 12~36V DC |
| Power Consumption | 16W |
| Current at 12V | 1333 mA max |
| Working Temperature | 0°C to +60°C |
| Mounting Method | Panel Mounting & VESA |
