Display
Size
10.4 inches
Resolution
1024×768
Type
Projected Capacitive Multi Touch
Panel Brightness
400 nits 800 nits(Optional)
Contrast Ratio
1200:1
View Angles
88,88,88,88
Touch Mode
Support Hand, Stylus, Glove Mode
System Specification
Processor
Qualcomm® Snapdragon™ 660 (Octa-Core 2.2 GHz)
Memory
3GB
Storage
32GB
Operating System
Android 9.0
WLAN
Support
BT
Support
WWAN
4G/LTE (Optional)
GNSS
GPS/GLONASS (Optional)
Sensors
G-Sensor, Temp. Sensor
Camera
Front Camera
2MP Camera
Mechanical
Dimension
268 x 214 x 51 mm
Weight
2.4 kg
Mounting
RAM Mount/ VESA Mount
Cooling System
Fanless Design
IO Ports
USB Port
1 x USB 3.0 Type C (OTG) 1 x USB 2.0 Port
Serial Port
2 x RS232/422/485 (Default RS232)
LAN
1 x Gigabit LAN port PSE (IEEE 802.3at 30W) (Optional)
Audio
1 x Audio(Mic in & Line Out) either one with DIDO (Optional)
SD Card Slot
1 x Micro SD Card Slot
SIM Card Slot
1 x Dual-Nano SIM Card Slot
Indicator
5 x LED Indicator (Wi-Fi, BT, UPS battery, Screen Blanking, Heater)
DIDO
1 x DIDO (2XDI ? 2XDO) either one with Audio (Optional)
CANBUS
1 x CANBus (Optional)
Environment
Operating Humidity
5% to 95% RH, Non-Condensing
Operating Temperature
-30°C to 50°C
Storage Temperature
-30°C to 60°C
Shock
MIL-STD-810H Method 516.8 Procedure I
Vibration
MIL-STD-810H Method 514.8 Procedure I
IP rating
IP65
Impact
Support EN62262 IK07 Rating
ESD
Compliant with EN 61000-4-2, Enhanced ESD to ±8kV Direct & ±15kV Air
Certification
Certification
CE, FCC
Control
Button
1 x Power Button, 6 x Function Button (Programmable Function Key Configured by Winset)
Power
Battery
400mAh UPS Battery for 20 minutes backup (Optional)
Power Rating
10V~60V with ignition control
Security Function
SOTI MobiControl
SOTI MobiControl Compliance
Accessory
Accessory
5M Power Cable with Fuse Kit 0.15M Power Converter Cable DC Jack Power Cable 84W Adapter with power cable Quick Start Guide
Optional Accessory
Stylus Kit + Screw 1.8M RS232 Cable 2M IP65 LAN Cable GPS & LTE 2M Combo Antenna(VM240) GPS & LTE 5M Combo Antenna (VM9C) GPS & LTE Magnetic Combo Antenna (VM10S) GPS Antenna WWAN Antenna 2M Waterproof USB Type-A to A Cable Cable Clamp Kit COM Port + CANBus Cable COM Port + DIDO Cable
