Display
Size
10.4 inches
Resolution
1024×768
Type
Projected Capacitive Multi Touch
Panel Brightness
400 nits 800 nits(Optional)
Contrast Ratio
1200:1
View Angles
88,88,88,88
Touch Mode
Support Hand, Stylus, Glove Mode
System Specification
Processor
Qualcomm® Snapdragon™ 660 (Octa-Core 2.2 GHz)
Memory
3GB
Storage
32GB
Operating System
Android 9.0
WLAN
Support
BT
Support
WWAN
4G/LTE (Optional)
GNSS
GPS/GLONASS
Sensors
G-Sensor, Temp. Sensor
Camera
Front Camera
2MP Camera
Mechanical
Dimension
Tablet: 268 x 214 x 35 mm (10.6 x 8.42 x 1.37 inches) Docking: 202 x 245 x 52 mm (7.9 x 9.6 x 2.04 inches)
Docking Housing
Aluminum Alloy Housing
Weight
Tablet 1.6 kg (3.53 lbs) Docking 1.6 kg (3.53 lbs)
Mounting
RAM Mount/ Vesa Mount
Cooling System
Fanless Design
IO Ports
USB Port
1 x USB 3.0 Type C (OTG)(Tablet) 1 x DB9 Connector for 2 x USB 2.0 Port(Docking)
Serial Port
2 x COM Port(Docking)
LAN
1 x Gigabit LAN port(Docking)
Audio
2 x Speaker(Docking) 1 x CANBus or 1 x Audio(Docking)
SD Card Slot
1 x Micro SD Card Slot(Tablet)
SIM Card Slot
1 x Dual-Nano SIM Card Slot(Tablet)
Indicator
5 x LED Indicator (Wi-Fi, BT, UPS battery, Screen Blanking, Heater)
Environment
Operating Humidity
5% to 95% RH, Non-Condensing
Operating Temperature
-30°C to 50°C
Storage Temperature
-30°C to 60°C
Shock
MIL-STD-810G Method 516.6 Procedure I
Vibration
MIL-STD-810G Method 514.6 Procedure I
IP rating
IP65
Impact
Support EN62262 IK07 Rating
ESD
Compliant with EN 61000-4-2, Enhanced ESD to ±8kV Direct & ±15kV Air
Certification
Certification
CE, FCC
Control
Button
1 x Power Button, 6 x Function Button (Programmable Function Key Configured by Winset)
Power
Battery
7.6V UPS Battery (2S1P) Minimum 30 minutes
Power Rating
Docking: 10V-60V with ignition control Tablet: 12V DC In
Security Function
SOTI MobiControl
SOTI MobiControl Compliance
Accessory
Accessory
5M Power Cable with Fuse Kit 0.3M USB Cable 0.15M Power Converter Cable DC Jack Power Cable 84W Adapter with power cable Cable Clamp Kit Wi-Fi Antenna x 2 Quick Start Guide External Antenna Fixing Bracket Dock + Latch Locking Key Stylus Kit + Screw
Optional Accessory
1.8M RS232 Cable 0.3M Audio Cable 1.8M CAN BUS Cable 1.8M CAN BUS Open Wire Cable 2M IP65 LAN Cable GPS & LTE 2M Combo Antenna(VM240) GPS & LTE 5M Combo Antenna (VM9C) Magnetic Combo Antenna (VM10S) WWN Antenna HDMI Adapter
