System Specification
Processor
ARM A53 (Quad Core 2.0GHz)
Memory
4GB LPDDR4
Storage
eMMC: Onboard 32 GB
Security
SOTI MobiControl Compliance
Operating System
Android 11 (Upgradeable to Android 13) Linux Yocto 5.10.104 with QT 5.15 (Optional) Linux Ubuntu (Optional)
WLAN
Support (Optional)
BT
Support for Android (Optional)
WWAN
4G/LTE (Optional)
Expansion Port
EACWSLT-231 3-port RS232/422/485 w/ isolation EACWSLT-232 16-Channel Digital I/O w/ isolation EACWSLT-233 2-port CANBUS w/ isolation EACWLST-234 3-port USB 2.0 EACWLST-235 2-port RS232/422/485 w/ isolation
Mechanical
Dimension
100 (W) x 70 (H) x 31(D) mm(One layer) 100 (W) x 70 (H) x 61(D) mm(Double layer)
Weight
0.4 kg (One layer), 0.5 kg (Double layer)
Mounting
Desk Mounting & Wall Mounting VESA Mounting (Optional) DIN-Rail Mounting (Optional)
Cooling System
Fanless design
Environment
Operating Humidity
30% to 90% RH, Non-Condensing
Operating Temperature
0°C to 55°C
Storage Temperature
-15°C to 70°C
Shock
Operating, IEC 60068-2-27
Vibration
Operating, IEC 60068-2-64
IP rating
IP30
Certification
Certification
CE, FCC Microsoft Azure Certified for IoT
IO Ports
USB Port
2 x USB2.0 (Type-A) 1 x USB2.0 OTG (Micro USB), support Android Debug Bridge (adb)
LAN
2 x Giga LAN RJ45 Connector for Linux 1 x Giga LAN RJ45 Connector for Android
Video
1 x HDMI (Up to 1080p/30Hz) (Optional)
Expansion Port
1 x M.2 slot 2 x USB Wafer
Indicator
1 x LED Indicator for power
Power Input
1 x 9~36V DC, 2-Pin Terminal Block
Control
Button
1 x Power Button 1 x Reset Button
Accessory
Accessory
Terminal Block 2 pin to 2.5Ø Female Adapter Cable Quick Start Guide Open Wire Cable WLAN External Antenna*2 (For WLAN sku) WWAN External Antenna*2 (For WWAN sku) BT External Antenna*1 (For BT sku)
Optional Accessory
AC to DC Adapter 12V/36W (Optional) VESA Mount Kit (Optional) DIN Rail Mount Kit (Optional) Micro USB to Type A Cable (Optional)
Power
Power Rating
9V~36V DC, 2-Pin Terminal Block
Adapter
12V 36W (Optional)
Ordering Information
Option
EACIM20-100 Standard SKU EACIM20-101 with WLAN and BT SKU (Optional) EACIM20-102 with WWAN SKU (Optional) EACIM20-103 with WLAN, BT and WWAN SKU (Optional) EACWSLT-231 3-port RS232/422/485 w/ isolation (Optional) EACWSLT-232 16-Channel Digital I/O w/ isolation (Optional) EACWSLT-233 2-port CANBUS w/ isolation (Optional) EACWSLT-234 4-port USB 2.0 (Optional) EACWSLT-235 2-port RS232/422/485 w/ isolation (Optional)
